Scandia Heater Spare Parts - Sawotec SCA-45NS Bedienungsanleitung

Safety
Regulating Sensor
Sensor
4,5 kW
21
HP02-012
22
HP01-021
HP01-015
6,0 kW
8,0 kW
9,0 kW
SCA-45NS
SCA-60NS
SCA-80NS
SCA-90NS
23
HP02-024- NB Model
HP02-024-1 NS Model
SCA-45NB
SCA-60NB
SCA-80NB
SCA-90NB
(PREMIUM MODEL)
14
16
17
HP01-016

SCANdIA HEATER SPARE PARTS

1. Backframe
2. Frontframe
3. SCA Stone Holder
4. Heating Element
5. Name Plate (Small)
6. Wall Mounting Rack
7. SCA Mid Reflection Sheet
8. Heating Element Holder with O-rings
9. Timer Knob
10. Timer Pilot Lamp
11. Timer Switch
12. Sensor Lock
13. Thermostat Switch
14. Thermostat Pilot Lamp (Premium only)
15. Terminal Block (Small White)
16. Front Cover
17. Thermo Knob
18. Cable Clip with Wings
19. Control Unit Body
20. SCA Cable Conduit Channel with Bottom Cover
21. Cable Box for SCA Separate Control Unit
22. Cable Holder
23. SCA Wire Set 4,5-9,0 kW
24. Reflection Sheet
25. SCA Catchpan
9
10
11
13
HP01-013
HP01-022-A1
15
HP01-017
18
HP01-009
HP01-011
12
HP01-008
19
HP02-011
20
DEUTSCH | ENGLISH
25
