DK50 2x2V/110
Compressor cabinet
S110
1/N/PE ~ 230V/50Hz
ELECTRIC OBJECT OF 1st. CAT.
bn bu bk gy
5G0.75
-X10
1
Legend for electrical diagram
M1,M2 Compressor motor
E1,E2 Compressor fan
E3 Dryer fan
M10,M20 Relief valve
B2 Temperature switch
E10,E11 Cabinet fan
X10 Connector
X2 Socket
Note:
* - For 8-10 bar compressor models, an hourly meter is installed on the pressure switch.
** - Only connect the jumper for compressorswithout cabinet (Chapter.19.11)
10/2018
-S10
PE
3G0.5
N 2 3 PE
gn
1
PE
bn
bu
-E10 -E11
B1 Pressure switch
X1 Terminal strip
M4 Condensate drain valve
P1* Hour meter
S10 Switch
K1 Timer relay
F1,2 Breaker
Q11,12 Contactor
- 25 - NP-DK50 2x2V 110-2_10-2018-MD A
