English
STEP 1: Check the contents of the box
Check you have all the components and your drive has not been damaged during transportation.
STEP 2: Check model and voltage
The model number can be found on the identification label
and the drive voltage range is suitable for the installation.
M400-034 00073 A
2
KIT BAG
CABLE BRACKET
+ +
x4
1
Derivative
M400 -
Product line:
Frame size:
:
Voltage rating
1 - 100 V (100 - 120 ± 10 %)
2 - 200 V (200 - 240 ± 10 %)
4 - 400 V (380 - 480 ± 10 %)
SAFETY
INFORMATION
+
on the top of the drive. Please check that the model
1
Electrical Specifications
03 4 00073
Current Rating :
Heavy Duty current rating x10
Unidrive M400 Step By Step Guide
STEP BY STEP GUIDE
A
Drive Format :
A – AC in AC out
Issue Number: 2
