1. Maßblatt HKF 200 E / HKF 200 C
Lochbild des
Befestigungsflansches
Ø 250
Zone 1
Kategorie 2 bzw. 3
Zone 0/20
Kategorie 1
X= Mindest-Einführungs Ø180
XX= Rotations Ø200
C1
C. Technische Daten
Kabeleinführung Rundkabel
min. Ø 10mm 4x1,5mm²
Druckanschluss M22x1,5
Lochkreis Ø225
Flansch Ø250
Ø 30
vorgeschriebene
Drehrichtung
x
xx
HKF 200
Aufhängebügel
Best.-Nr. 4.034-126
5.956-515
