1. Machine overview (standard delivery)

11
10
9
8
7
Combination radial pull and table saw
secanta :
1 Riving knife
2 Housing in honeycomb design,
made of magnesium alloy
3 Rotating table turnning through
180°
4 Centralized control unit
A Multifunctional handwheel
for mitre
handwheel sideways
for bevel setting: turn hand-
wheel
radial pull action: lift hand-
wheel and pull
B Locking key for mitre angle
16

Operating Instruction

C Lock lever for mitre angle lock-
D Lock lever (2x) for bevel angle
E Crank for cutting height setting
F ON/OFF switch
5 Push stick
6 Folding workstand
7 Track arm locking device
setting: move
Standard accessories
8 Plug for suction port (2x)
9 Fence – use as mitre or rip fence
10 Blade guard
11 Suction hose for blade guard
ENGLISH
C
2
1
3
ing
locking
B
D
A
E
F
D
Tools supplied
Combination wrench 13 mm
Combination wrench 10 mm
Allen key 6 mm
Allen key 4 mm
Machine documents
Operating instructions
Spare parts list
4
5
6
