SOMFY Power 4x2.5 DC RTS Gebrauchsanleitung Seite 88

BOX
INPUT
OUTPUT
RADIO
PROTOCOL
POWER SUPPLY
SPECIFICATIONS
STANDARDS
TEMPERATURE
RANGE
CONNECTORS
INSTALLATION
DISTANCE
86
Material
Color
Size
Protection factor
Weight (net)
Range of supply voltage
Frequency
No load power consumption
Max wire size for terminals
Fuse
Nominal load (maximum conti-
nuous current)
Voltage
Ripple (peak to peak)
Total regulation
Max wire size for terminals
Fuse
Type
frequency
Type
Standards reference
Insulation class
Working / running time
Storage
Rate of humidity relative
Input
Output
Distance mini between a motor
and a receiver
Distance mini between the floor
and the receiver
Distance mini between 2
receivers
Copyright © 2010 Somfy SAS. All rights reserved - V0 - 04/2010
plastic
white
155 x 155 x 53,6 (mm)
IP20
520gr
198-255 V AC
50 Hz
0,7 W
1,5 mm²
Fuse
2,5A
24Vdc SELV regulated
< 500mV
+ / - 5% (22,8V to 25,2V)
1,5 mm²
Autorecovery
Somfy RTS protocol
433,42MHz
SMPS (switching mode pwr
supply)
EN50022 classB EN 61058
Class II
-10°C to +35°C / 24min ON,
30min OFF, 24min ON
-35°C to +55°C / 12min ON,
30min OFF, 12min ON
-30°C to +80°C
85% HR at 30°C
screw terminal:IEC320 C8 (2P)
screw terminal
30 cm
1,5 m
30 cm
