C.4) Adjusting or readjusting the blind:
C.4.a) Choosing the type of mode :
To skip from one mode to the other, press
the My and Down buttons for approximately
2 seconds until the blind moves up and down.
Power
The 4x2.5 DC RTS Receiver in roller
mode :
The UP and Down movement is without stop
at the down end limit.
Power
The 4x2.5 DC RTS Receiver in
Venetian mode :
During the Up and Down movement, there is
a stop at the down end limit.
C.4.b) Motor rotation direction :
Press the Up or Down button to verify the
rotation direction.
If the direction is incorrect, press the My
button until the blind moves up and down.
Verify the rotation direction using the Up and
Down buttons.This operation can be repeated
severaltimes.
The direction is inverted every time the My
button is pressed for 2 seconds.
C.4.c) Tilting using the Mod/Var Scroll wheel :
Use the scroll wheel to verify the slats tilting.
If the direction is incorrect, press the Up,
My and Down buttons for approximately 2
seconds until the blind moves up and down.
The Scroll wheel operational position has
been inverted.
This operation can be repeated several
times.
The operational position is inverted every
time the Up and Down buttons are pressed
for approximately 2 seconds.
Note: The slat tilting behaviour is indepen-
dent of the motor rotation direction.
