C ADJUSTING THE BLIND
End limits are operated by the motor and its
accessories and not by the Power 4x2.5 DC
RTS Receiver.
C.1) Connect the Power 4x2.5 DC RTS
Receiver (It is necessary to take all the
precautions of use to protect the Power 4x2.5
DC RTS Receiver from the electrostatic
discharges).
If several motors are connected to the
same outpout of the Power 4x2.5 DC RTS
Receiver, the adjustment will be commun to
all the motors.
C.2) Choise of the output
Before setting a blind, you need to select the
output on which it is connected (by defect,
output 1 is active).
A first short press on the programming button
allows to check which output is active.
Output 1 (S1) → 1 beep
Output 2 (S2) → 2 beep
Output 3 (S3) → 3 beep
Output 4 (S4) → 4 beep
A 2nd short press allows to move from one
output to the other in the chronological order
(1 → 4).
To be valid, the 2nd short press must be
carried out the 5s maximum after the 1st
short press.
Settings are only valid for the
selected output.
Copyright © 2010 Somfy SAS. All rights reserved - V0 - 04/2010
2x0,75mm
2
2x0,25mm
<5s
<5s
<5s
2
S1
S2
S3
S4
