A COMPATIBLE APPLICATIONS
1)
Compatible controls
The Power 4x2.5 DC RTS Receiver is compatible with all Somfy RTS transmitters
with a maximum of 40 transmitters and 6 sensor per DC RTS Receiver.
2) Compatible blinds:
a. Venetian blinds
b. Roman shades
c. Pleated shades
d. Cellular shades
e. Ballon shades
f . Pinoleum shades
B INSTALLATION AND WIRING
A : 198 - 255V ~ 50Hz
B : 24V TBTS +/- 5%
C : PROG -Taste
