C.2) Setting through the remote control:
Remark: When controlling through a
remote control, all Power 4x2.5 DC RTS
Receiver are adjusted at the same time if
several Power 4x2.5 DC RTS Receiver are
connected.
Pairing:
Briefly press the Up and Down buttons on the
remote control.
The blind moves up and down.
The remote control is temporarily saved.
Settings:
Refer to steps:
C4a: Choosing the type of blind :
C4b: Motor rotation direction :
C4c: Orientation using the dial :
C4a C4b C4c C4d C4e
C4d: Sun sensor operation :
C4e: Duration of raising and lowering of the
blind
Saving:
Briefly press the programming button on the
remote control.
The blind moves up and down.
The remote control is permanently saved.
