Housing:
Overall dimensions: 120 (pin output) or 103 (BNC output) x 64 x 28mm

Output by two male pins, dia. 4mm, 19mm centres, or by a coaxial cable 40 cm

long terminated by an insulated female BNC connector.
Mass of the instrument: approximately 200g.
Index of protection:
Flammability rating:
Flexible sensor:

Housing:

The flexible coil is resistant to oils and aliphatic hydrocarbons.

3.9. COMPLIANCE wITH INTERNATIONAL STANDARDS

Electrical safety as per IEC 61010‑2‑032 (Ed. 2 of 2003) for type B sensors.
Double insulation
Measurement category: III
Rated voltage: 600V
(1): or 300V in category IV.
(2): or 1000V in category III.

3.10. ELECTROMAGNETIC COMPATIBILITy

The instrument satisfies the EMC and LVD directives required for the CE marking
and product standard IEC 61326‑1 (Ed. 97) + A1 (Ed. 98).
Immunity in industrial environment

Emissions in industrial environment.

IP 50 as per IEC 60529 (Ed. 92)
IK 04 as per IEC 50102 (Ed. 95)
V0 (as per UL 94)
V2 (as per UL 94)
Housing
(1)
Double insulation
Measurement category: IV
Rated voltage: 600V
9
Sensor
(2)
