16.2
Wood
The location to be measured should be un-
treated, free of knots, dirt and resin. Measure-
ments should not be made on the end faces
of wood because these areas dry particularly
quickly such that they produce incorrect
measurement results. Perform multiple
comparative measurements. Wait until
the % symbol stops blinking and remains
constantly lighted. Only then are
measurement values stable.
16.3
Mineral building materials
Be aware that walls (or surfaces) with differing
material structures, or even variations in
material composition, can cause measurement
results to be falsified. Perform multiple
comparative measurements. Wait until
the % symbol stops blinking and remains
constantly lighted. Only then are measure-
ment values stable.
17
Instruction for use - capacitive measuring principle
Place the device such that the sensor
pads fully rest on the material to be
measured and exert a pressure of
about 2.5 kg onto the surface to be
measured.
TIP: Use scales to test the contact
pressure.
30
EN
Always hold and press down the
measuring device in the same way
(see illustration).
