4. Press the button to open the dust container. The bottom of the dust container will
open and the dirt will fall out.
5. Shut the dust container bottom again. The fastener must audibly lock into place.
6. Put the dust container in the device: Take it by the handle and insert it bottom fi rst
into the device. Then push the handle towards the device housing until the dust
container audibly clicks into place. Hold the device by the dust container handle and
lift it up to check that the dust container is correctly locked into place.
Cleaning the cyclone insert and motor fi lters
The cyclone insert is situated inside the dust container. The motor fi lters are situated in
the fi lter holder on the cyclone insert.
1. Remove the dust container from the device and empty it (see section "Emptying the
dust container").
2. Turn the lid of the dust container as far as it will go in an anticlockwise direction.
Remove the lid.
6. If required, rinse out the fi lters thoroughly with clear, lukewarm water.
Attention: Do not use any cleaning products!
Next shake off any surplus water and leave the fi lters to air dry completely before
replacing them in the device.
7. You can clean the cyclone insert and dust container with a damp cloth.
8. When all parts are dry, replace the cyclone insert in the dust container.
Please note: There is an arrow symbol on the top of the cyclone insert. Place the
cyclone insert into the dust container so that this arrow symbol points to the
symbol on the dust container.
9. After drying, place the foam fi lter back into the fi lter holder and replace the holder
onto the cyclone insert.
Attention: Never put damp parts back into the dust container!
10. Put the lid on the dust container so that the arrow symbol on the lid points to the
symbol on the dust container. Close the lid by turning it as far as it will go. The arrow
symbol should now be pointing to the
11. Put the dust container in the device. Make sure that it audibly locks into place.
If the fi lters are damaged or worn you can order new fi lters at
www.service-shopping.de.
3. Carefully remove the cyclone insert (B) from the dust
C
container.
4. Pull the fi lter holder (C) out of the cyclone insert and
remove the foam fi lter.
B
Please note: The second motor fi lter is attached to the
fi lter holder and cannot be removed from the holder!
5. Tap out all the parts over a bin and brush away any loose
dirt.
symbol on the dust container.
