Product- and functional description

Introduction
This section will give you a description of the CDT 20/30/40/60 and its functionality:
Principles of opera-
The following describes the air flow
tion
through the dehumidifier:
A fan draws in humid air through a fil-
The air is reheated by e.g. the opera-
crease in temperature is +5 °C/41 °F)
Due to the repeated air circulation through the dehumidifier, the air humidity is continu-
ously reduced whereby achieving rapid but gentle drying.
The dehumidifier will operate continuously unless a hygrostat (Accessories, see page
55) is connected.
Illustration
This illustration gives an overview of the dehumidifier:
Water tank
Water is collected in the water tank. Alternatively, you can also setup the dehumidifier
for permanent drainage with the adapter for hose connection (Accessories, see page
55).
When the water tank is full, the dehumidifier shuts off automatically.
See "User's guide", page 51 on how to drain the water tank.
Operation of the unit is not possible once the water tank is removed.
The air flow
through the dehumidifier
ter to the dehumidifier
The air is cooled down and humid-
ity/water drops are led down to the
water tank
tion of the dehumidifier (approx. in-
Front view
Handle for transport
Operator control
Power cable
Exhaust air outlet
Supply air outlet
with PPI filter
behind the grill
Water tank
Wheels
Rear view
Continued overleaf
47
