1-2 Rack Installation Guide


The rack kit includes the following items (see Figure 1-1):
•
Two center-mount brackets
•
Four 10-24 x 0.375-inch pan-head Phillips (or slotted) screws
•
Two 12-24 x 0.5-inch pan-head Phillips screws
center-mount brackets (2)
12-24 x 0.5-inch pan-head
Phillips screws (2)




You need the following tools and supplies to install the system in a two-post open-
frame relay rack:
•
#2 Phillips screwdriver
•
Masking tape or a felt-tip pen, for use in marking the mounting holes to be used
10-24 x 0.375-inch pan-
head Phillips screws (4)
