Please read these instructions carefully before installing the control unit.
Improper use or a connection error could jeopardise correct operation of the product and endanger
the end user.
FEATURES
The control unit has:
- built-in receiver for TANGO transmitters (T200 SW also available for TANGO SW transmitters)
- electronic torque control
- motor slowdown
- photocell operating test (Foto Test)
- motor self-diagnosis (Triac Test)
- set-up for anti-crushing protection (optional module MAS200)
TECHNICAL DATA
Electrical parameters:
Power supply
Frequency
Stand-by input
Maximum input
Max. motor power
Working temperature
Enclosure Dimensions (W x H x D)
Radio parameters:
Transmitter model
Reception frequency
Storage capacity
GENERAL LAYOUT (Fig. 1)
1 Terminals for the connection of the mains supply
2 Line fuse 230V 6.3A (5x20)
3 Programming LED (L1)
4 Optional anti crushing board MAS200
5 Low voltage fuse 24V 2A (5x20)
6 Terminals for the connection of the courtesy and flashing lights
7 Terminals for the connection of the motors
8 Terminals for the connection of the antenna and radio receiver, second channel
9 Built-in radio card compatible with the TANGO SW transmitter range
10 Connector for the card receiver
11 Dipswitch functions
12 Control unit reset, momentarily short-circuiting the 2 pins resets the unit.
U.M.
Vac
Hz
mA
A
VA
°C
mm
Tango / Tango SW
serie
Mhz
Nr
T200
230 ±10%
50
20
5
1100
-20 +60
200x255x100
433.920
140
49
