Conceptronic C54APRA2+ Schnellstartanleitung Seite 51

ENGLISH
6. Select the LAN IP for the computer that needs the Virtual Server Rule. If the IP is
not in the list (for example: if the device uses a Static IP) you can use the "New
IP" Button to add the device IP.
7. Select the Category for your Virtual Server Rule.
Note: There are several rules pre-defined in the configuration. You can select 1 of
the pre-defined rules or create a new rule by selecting the "User" Category
and press the "New" button.
8. Select the Rule you need for your forwarding.
9. Press the "Add" button to attach the selected Rule to the selected IP Address.
10. If all Rules are defined, press "Apply" to save the settings.
Note: After the Virtual Server Rules are configured, the C54APRA2+/C54APRB2+
needs to be rebooted. Please continue to "Chapter 8" for reboot
instructions.
After reboot the defined Rules are ready to use!
51
