• Back Panel
1
2
Nr Description
1 Antenna Connection
2 Reset Button
(Not visible on picture)
3 ADSL Connection
4 LAN Ports
5 Power Connection
6 Power Switch
Note: For detailed explanation of the C54APRA2+/C54APRB2+ please see the User
Manual (English only!) on the included CD-ROM. Select "View User Manual"
from the Autorun Menu.
Note: This Quick Installation Guide only explains the basic steps to get the
C54APRA2+/C54APRB2+ up and running.
For more info about the various functions of the C54APRA2+/C54APRB2+
please see the User Manual (English only!) on the included CD-ROM. Select
"View User Manual" from the Autorun Menu.
3
Explanation
Reverse-SMA Connector for Wireless Antenna
Reset the device to the Factory Default Settings
(Press and Hold for +/- 10 seconds)
Connect your ADSL Line to the device
Connect your Computer(s) to the device
Connect the Power Supply to the device
Turn the device on or off
