Replacing the fuse

If the fine-wire fuse of the device fuses, only replace the fuse by a fuse of same type and rating.
Before replacing the fuse, unplug mains lead.
Procedure:
Step 1: Unscrew the fuseholder on the rearpanel with a fitting screwdriver from the housing (anti-
clockwise).
Step 2: Remove the old fuse from the fuseholder.
Step 3: Install the new fuse in the fuseholder.
Step 4: Replace the fuseholder in the housing and fix it.
Should you need any spare parts, please use genuine parts.
If the power supply cable of this device becomes damaged, it has to be replaced by a special power supply
cable available at your dealer.
Should you have further questions, please contact your dealer.

TECHNICAL SPECIFICATIONS

Power supply:
Power consumption:
DMX control channels:
DMX512 connection:
Sound-control:
Flash-rate:
LED type:
Number of LEDs:
Beam angle:
Dimensions (LxWxH):
Weight:
Maximum ambient temperature T
Maximum housing temperature T
Min.distance from flammable surfaces:
Min.distance to lighted object:
Fuse:
Please note: Every information is subject to change without prior notice. 04.09.2013 ©
:
a
(steady state):
C
34/34
100-240 V AC, 50/60 Hz ~
105 W
4/6/10/48/52
3-pin XLR
via built-in microphone
30 Hz
8 W QCL
12
22°
1041 x 65 x 162 mm
4.25 kg
45° C
65° C
0.5 m
0.1m
T 3.15 A, 250 V
00078164.DOC, Version 1.0
