Control Board

The Control Board offers several features: you can simply set the starting address, run the pre-programmed
program or select a DMX channel mode.
MODE
ENTER
Menu level 1
A u t o
1
< A u t o 1 >
S t a t i c
2
S o u n d
3
S o u n d
S e n s e
4
< 1 0 0 >
Browse through the menu by pressing Mode. Press Enter in order
UP
to select the desired menu. You can change the selection by
pressing Up or Down. Press Enter in order to confirm. You can
leave every mode by pressing Mode. The functions provided are
listed in the following sections.
DOWN
Menu level 2 (flash)
A u t o
< A u t o 1 >
< A u t o 2 >
< A u t o 3 >
< A u t o 4 >
< A u t o 5 >
< A u t o 6 >
< A u t o 7 >
< A u t o 8 >
< A u t o 9 >
< A u t o 1 0 >
< A u t o 1 1 >
< A u t o 1 2 >
< F a d e >
S t a t i c
< F i x C >
< M a n u C >
S o u n d
S o u n d 0
S o u n d 1
S o u n d 2
S o u n d 3
S o u n d 4
S o u n d 5
0 S o u n d 6
S o u n d 7
S o u n d 8
S o u n d 9
S o u n d 1 0
S o u n d 1 1
S o u n d 1 2
S e n s e
< 1 0 0 >
Flash Comment
Auto program
S p e e d
(12 + fade program)
< 1 0 0 >
Speed: 0-100 (increasing)
Default setting: 100
Static colors
F i x C
< R >
Default setting：RGBW
< G >
< B >
< W >
< G B >
< R B >
< R G >
< R G B >
< R W >
< G W >
< B W >
< R G W >
< R B W >
< G B W >
< R G B W >
M a n u a l C
< R = 0 0 1 >
< G = 0 0 1 >
< B = 0 0 1 >
< W = 2 5 5 >
Sound controlled program
Sound 0: Random program
Sound 1-12: Sound controlled program 1-12
Default：Sound 0
Microphone sensitivity: 0-100
Default setting：80
32/34
V a l u e
< R = 0 0 1 >
< G = 0 0 1 >
< B = 0 0 1 >
< W = 2 5 5 >
00078164.DOC, Version 1.0
Dimmer intensity
of LED colors
Default settings：
R=255 G=255
B=255 W=255
