1.2 Protect yourself from electric shock by insulating
yourself from work and ground.
1.3 Disconnect input plug or power before working on
machine.
2 Breathing welding fumes can be hazardous to your
health.
2.1 Keep your head out of fumes.
2.2 Use forced ventilation or local exhaust to remove
fumes.
2.3 Use ventilating fan to remove fumes.
3 Welding sparks can cause explosion or fire.
3.1 Keep flammable materials away from welding.
3.2 Welding sparks can cause fires. Have a fire extin-
guisher nearby and have a watchperson ready to use
it.
3.3 Do not weld on drums or any closed containers.
4 Arc rays can burn eyes and injure skin.
4.1 Wear hat and safety glasses. Use ear protection and
button shirt collar. Use welding helmet with correct
shade of filter. Wear complete body protection.
5 Become trained and read the instructions before
working on the machine or welding.
6 Do not remove or paint over (cover) label.
2 GENERAL DESCRIPTIONS
2.1 SPECIFICATIONS
This welding machine is a constant current generator
built using INVERTER technology, designed to weld with
covered electrodes and for TIG procedures, with contact
starting.
IT MUST NOT BE USED TO DEFROST PIPES.
2.2 EXPLANATION OF THE TECHNICAL SPECIFICA-
TIONS LISTED ON THE MACHINE PLATE.
This machine is manufactured according to the following
international standards: IEC 60974.1.
N°. Serial number, which must be indicated on
any type of request regarding the welding
machine.
Single-phase static transformer-rectifier
frequency converter.
Drooping characteristic.
SMAW. Suitable for welding with covered elec-
trodes.
TIG Suitable for TIG welding.
U0. Secondary open-circuit voltage
X. Duty cycle percentage. % of 10 minutes
during which the welding machine may run
at a certain current without overheating.
I2. Welding current
U2. Secondary voltage with current I2
U1. Rated supply voltage.
The machine has an automatic supply volt-
age selector.
1~ 50/60Hz 50- or 60-Hz single-phase power supply
I1 max. This is the maximum value of the absorbed
current.
I1 eff. This is the maximum value of the actual cur-
rent absorbed, considering the duty cycle.
IP23S Protection rating for the housing.
Grade 3 as the second digit means that this
equipment may be stored, but it is not
suitable for use outdoors in the rain, unless
it is protected.
S
Suitable for hazardous environments.
NOTE:
The machine has also been designed for use in environ-
ments with a pollution rating of 3. (See IEC 60664).

2.3 THERMAL PROTECTION

This equipment is protected by a thermostat. When the
thermostat is tripped, the machine stops delivering cur-
rent but the fan continues to run. The yellow led (B) lights
to indicate when it is tripped. Do not shut off the welding
machine until the led has gone off.

2.4 MOTOR-DRIVEN GENERATORS

These must have a power equal to or greater than 6KVA,
and must not deliver a voltage greater than 260V.

3 INSTALLATION

This must be carried out by skilled personnel. All con-
nections must be carried out according to current regula-
tions, and in full observance of safety laws (regulation CEI
26-23 - CEI CLC 62081).
• Make sure that the supply voltage matches the voltage
indicated on the specifications plate.
• When mounting a plug, make sure it has an adequate
capacity, and that the yellow/green conductor of the
power supply cable is connected to the earth pin.
WARNING! Extension cords of up to 30m must have a
cross-section of at least 2.5 mm2.
7
