Basic Operation - DJ-Tech U2 Station Benutzerhandbuch

CONTROLS AND FUNCTIONS
5. BPM METER – Indicates the BPM value of the currently playing track.
6. PITCH METER – Indicates the percentage of a track's pitch.
7. TEMPO LOCK– Indicates if the tempo lock is activated (lock symbol).
8. LOOP INDICATOR – Indicates if LOOP function is activated.
9. RELOOP INDICATOR – Indicates if a loop has been set which can be activated with the Reloop function.
10. AUTO CUE STATUS – Indicates if Auto Cue is activated.
11. TIME DISPLAY – Indicates the time of the chosen Time mode in minutes, seconds and frames.
12. ALPHANUMERIC DISPLAY– Indicates the current name of the track, of the folder and the sampling rate.
For VBR recorded MP3 tracks the display only show "VBR". All kinds of other interactive information is also
shown.
13. TIME MODE –Indicates the elapsed time of a track ("ELAPSED") or the remaining time of a track
("Remain").
14. REPEAT INDICATOR – Indicates whether the unit is in REPEATED play mode.
15. SINGLE INDICATOR – Indicates whether the play mode is set to single ("SINGLE") or continuous mode
(no display).
16. TRACK INDICATOR – Indicates the number of the currently playing track.
17. PLAY/PAUSE INDICATOR – Indicates the device is in play mode (" "), or the player is in pause mode (" ").

BASIC OPERATION

SOURCE SELECT functions
1. MUSIC SOURCE DEVICE SELECT
There is a SOURCE SELECT BUTTON to select the music source playback in PLAYER by your desires.
You have two different choices as below:
(a) PLAYBACK from USB port A
Gently insert your USB stick, USB card reader, or compatible external hard drive into USB
A port and then press the SOURCE SELECTOR to select USB A for playing. At this time,
the USB A LED will glow.
(b) PLAYBACK from USB port B
Gently insert your USB stick, USB card reader, or compatible external hard drive into USB
B port and then press the SOURCE SELECTOR to select USB B for playing. At this time,
the USB B LED will glow.
Note: 1. To disconnect a USB drive, stop playback and "pull out" the USB connection.
2. This unit only support the "Removable Storage" type like a USB pen drive.
2.
CHANGE MUSIC SOURCE DEVICE
It must be in the pause mode, select the other USB port by pressing the SOURCE SELECT BUTTON. It
has no function when in the play mode.
7
LCD DISPLAY
