SYSTEM SETTING
CROSSFADER ACTIVE: Press the FOLDER knob to switch the CROSSFADER on and off. This fader is
used to mix the output signals of the left and right players.
CROSSFADER ACTIVE: OFF –The output signals of both players will be even.
CROSSFADER ACTIVE: ON –The mix signals from the left and right players according to the crossfader
position.
The default setting is CROSSFADER ON.
Reset all: In the "Reset all?" section, this will reset all your programmed menus and restore the unit to its
default settings. Press the FOLDER knob will return all function setting to default setting automatically and
then "reset OK" will display in the LCD.
FIRMWARE VERSION
This displays the unit firmware version. Firmware is the unit internal programming
code. Once enter setup mode and then turn the FOLDER KNOB to the last
submenus until Vxx.xx is displayed. "x's" are the version number.
FIRMWARE upgrade:
Step1: Copy the controller code or DSP code from PC and then save into memory device (Files must be in
root directory).
Step2. Turn the main power switch to off.
Step3: Turn the main power switch to on.
Step4: Insert USB memory device into USB port A to upgrade (Insert USB memory device into USB port B
to upgrade when "UpdateUI - -" is displayed) and "Update 10%~100%" will show in the display (for
DSP code), "UpdateUIxx" will show in the display (for controller code)
Step5: When upgrade is done"COMPLETE" will display, please removed memory device.
Step6: Turn the main power switch to off.
Step7: Turn the main power switch to on, if "UpdateUI - -" is displayed (failure), please repeat procedure step2
to step5.
Step8: Check the version number of the new firmware in the SETUP MODE
Step9: Done
Note:
1. Please delete the code in the memory device when upgrade has already done.
2. Power disconnection during processing or unknown memory device will cause failure.
