CONTROLS AND FUNCTIONS
1. SGL/CTN BUTTON – You can choose between "single track mode" and "continuous play".
Continuous play: all the tracks in the USB stick will be played in order without interruption.
Single track: player stops at the end of each track and waits at the beginning of the next track. Push the
SGL/ CTN button for more than 1 second to switch between normal and "auto cue" mode. In "auto cue"
mode the player waits at the first music note of each track.
2. TIME BUTTON – You can select different time display by pressing the TIME button to switch between
elapsed and remaining time.
3. USB PORT – This is the USB port where you insert your USB mass storage device for playing MP3 files.
4. SOURCE SELECT BUTTON – This button lets you toggle between USB Port A and B. In other words, you
can select which USB port will be activated and the relational LED will be lit. The function can only be
selected under pause mode.
5. INPUT SELECTOR SWITCH – The switch is used to select the input source, either USB or external
sources connected on the rear panel, assigned to channels 1-2. Each channel can only be assigned to one
input source each time.
6. MASTER VOLUME CONTROL – This rotary knob is used to control the master output level (volume).Be
sure this volume control is always set to zero before turning the unit on.
7. CHANNEL GAIN CONTROL – This adjustment is used to adjust an audio source signal input gain for a
channel. Never use the gain control to adjust output volume. Setting the gain level properly will ensure a
clean output signal.
Make sure not to set gain too high, so the inputs are not overloaded. If the inputs are overloaded, the
mixer will begin to distort. If that happens, decrease the gain on the overloaded channel.
8. CHANNEL EQUALIZER – All of the channels include a 3-band EQ. These controls are used to increase or
decrease the LOW's, MID's and HI's the output signal. Turning these knobs in a counter-clockwise
direction will decrease the amount of HIGH/MID/LOW applied to a channel signal, turning these knobs in a
clockwise direction will increase the amount of HIGH/MID/LOW applied to a channel signal.
KILL: Press the knobs to eliminate the LOW's, MID's and HI's frequency spectrum of the signal. The
corresponding KILL LEDs will illuminate when KILL is activated.
9. LCD DISPLAY – This high quality LCD display indicates all the functions, as they are occurring. This
display is viewable at several comfortable angles.
10. PITCH RANGE SELECTOR – Press this button to choose any pitch range percentages of 4%, 8%, 16%.
The default setting is 8%.
11. TEMPO LOCK BUTTON – This button is used to switch the TEMPO LOCK function on/off.
12. PITCH ON/OFF BUTTON – This button is used to turn the PITCH SLIDER function on and off. The pitch
percentage can be changed between 4%, 8%, 16%. 4% will allow the least amount of pitch manipulation
and 16% will allow the most amount of pitch manipulation.
13. TRACK KNOB – This knob is used to scroll backward and forward through tracks. Pushing this knob and
turning it at the same time will let you scroll forward or backward 10 tracks per "click" of the knob. Also,
when you press the knob it will toggle between artist, bit rate, title name, genre, and file name of the current
song playing out of the Player.
14. PITCH SLIDER – This slider is used to adjust the playback pitch percentage. The slider is a set adjustment
and will remain set until the pitch slider is move or the pitch function has been turned off. This adjustment
can be made with or without a music source device (USB A or USB B) in the player. The pitch adjustment
will remain even if a music source device (USB A or USB B) has been removed and will reflect on any
other music source device inserted into the player. That is to say, if you set a +8% pitch on one music
source device, remove that card and insert another, that music source device too will have a +8% pitch.
The amount of pitch being applied will be displayed in the LCD.
15. PITCH BEND BUTTONS – The speed rises while the "+button" is pressed and returns to the original pitch
when the button is released. The speed drops when the "–button" is pressed and returns to the original
pitch when the button is released. These buttons can be used to synchronize the beats of 2 tracks.
3
