CONTROLS AND FUNCTIONS
16. TAP BPM BUTTON – This button is used to override and manually set a track BPM. Occasionally the built-
in BPM meter may not function as desired. This button allows you to override the internal beat clock and
manually set a track BPMs. To manually set the BPMs; tap this button a few times to a tracks heavy down
beat, the unit will automatically calculate your tapping and translate it into a tracks BPMs. The BPM Readout
is then displayed in the LCD. To return to the automatic BPM counter, press and hold down the TAP
BUTTON for at least 2 seconds and then release.
17. SEAMLESS LOOP (See basic operation for more information.)
IN BUTTON – This function allows you to set a CUE POINT without music interruption. This button also
sets the starting point of a seamless loop.
OUT BUTTON – This button is used to set the ending point of a loop. A loop starting point is set by
pressing the IN BUTTON. Pressing the OUT BUTTON set the loop ending point. The loop will continue
to play until the OUT BUTTON is pressed once again.
RELOOP BUTTON – If a SEAMLESS LOOP has been made, but the Player is not actively in
SEAMLESS LOOP mode (a loop is not playing), pressing the RELOOP BUTTON will instantly reactivate
the SEAMLESS LOOP mode. To exit loop, press the OUT BUTTON. LOOP and RELOOP will appear in
the LCD DISPLAY when the RELOOP function is available.
18. DSP EFFECT
ECHO BUTTON – This button is used to activate and deactivate the ECHO effect.
FLANGER BUTTON – This button is used to activate and deactivate the FLANGER effect
FILTER BUTTON – This button is used to activate and deactivate the FILTER effect.
19. FOLDER KNOB – This knob is used to search through the folders on USB stick. Also, when you press the
knob it will show folder name of the current song playing out of the Player.
20. SEARCH BUTTONS – These buttons allows you to search fast backward or forward through the current
track whether in play mode or not.
This search button allows you to quickly scan backwards through a track.
This search button allows you to quickly scan forwards through a track.
21. JOG WHEEL – This wheel has 4 functions:
In the normal mode
The wheel works as a pitch bend during Playback. Turning the wheel clockwise can increase the
pitch percentage up to 100%, and turning the wheel in the counterclockwise direction can decrease
the pitch percentage down to -100%. The pitch bend will be determined on how long you turn the jog
wheel continuously.
The jog wheel acts as a slow frame search (1/75 sec) control when the music is not playing but either
paused or set to a cue point. To set a new cue point, spin the wheel then press PLAY or IN when you
have determined the proper position. Press CUE to return to the "CUE POINT".
In the SEARCH mode: Press SEARCH button to toggle between fast search and slow search.
SEARCH mode on (LED lit) – When the SEARCH function is activated you can use the jog Wheel to
search fast backward or forward through the current track whether in play mode or not.
SEARCH mode off (LED off) – When the SEARCH function is not activated, you can use the jog Wheel
to search frame by frame or a slow search in pause mode and you can use the JOG WHEEL act as a
PITCH BEND in play mode.
In the FX mode
Pressing or holding the ECHO/FLANGER/FILTER buttons will activate the FX function and the FX
button will glow. In this mode, you can reset the effect parameter by turning the JOG WHEEL. Holding
the FX button, the button will blink and you can change the effect parameter by turning the JOG WHEEL.
NOTE: The FX function can only be active by pressing or holding the ECHO/FLANGER/FILTER
buttons; otherwise it will be no function.
In the VINYL mode
Press the VINYL button to activate the VINYL function. You can scratch the track while in Play mode
with the Jog Wheel like a vinyl record, by moving it forward and backward and holding it. Press the
VINYL button a second time to deactivate the Scratch effect.
4
