Other Functions Remote Control; Temperature Indication; Automatic Shutdown With Low Battery Charge Status; Transporting, Storing The Device - Walimex Pro LED2Go 60 Daylight Gebrauchsanleitung

8.5 Other functions Remote control

• Switch on the light as described in section 8.1
• In standby mode, the light can only be set using the remote control. To do so, set the same
values on the remote control and the lamp as described in the previous sections
• Pressing the ON / OFF button on the remote control puts the LED light into standby mode
• Pressing the ON / OFF button on the remote control again turns the lamp on or off by remote
control
• When the lamp is turned off by the <ON / OFF> switch on the device, the remote control function
is not available
• Pressing the ON / OFF button on the remote control quickly turns the connected video lights on
and off.
• By pressing the SET button on the remote control for at least 2 seconds, all the video lights of
the current remote control group are switched on and off

8.6 Temperature Indication

• This video light checks its temperature at any time to avoid dangerous situations. It will auto
power off when the temperature is too high.
• Press the SET button for 2 seconds and the temperature can be switched between Celsius and
Fahrenheit.
• Quickly double-click the SET button, the temperature icon will blink, you can turn the select dial
to set the temperature (40°~60°) with fan.
When there are some abnormal situations in the inner video light, the relevant LCD signs will
blink as warnings. For example:
1. When the fan stops working due to fault, signs will blink to alarm.
2. When heatsink temperature is over 70 Celsius degrees, the temperature on the LCD panel will
blink and the video light will stop working.

8.7 Automatic shutdown with low battery charge status

When the battery level is low or becomes too low by the operation, the battery icon on device
display (7) the will blink and the video light will stop working.
NOTE
After use, disconnect the device from the local power supply by simply pulling out the mains plug.
9.

Transporting, storing the device

WARNING
Danger of fire caused by hot parts of the equipment. Allow the device to cool down completely.
• Switch off the device (See „Switching the device on, off).
• Allow the device to cool down completely.
• Unplug the power supply cable from the device.
• If necessary clean the device (See „Cleaning the device").
• Lay the device and all disassembled elements into the original article packaging box and
transport of store as specified in the technical specifications. See technical specifications.
36

10. Troubleshooting

Problem Possible cause
Mains cable not plugged in or
The device is switched on, but
not plugged in correctly. Bat-
does not show any function.
tery are almost exhausted.
The device is switched off.
LED lamps or display does
The device has not enough
not shine
power.
The device is defective.

11. Maintaining the device and cleaning

WARNING
Danger of electric shock and danger of fire due to short circuit.
Have the device repaired by an electrician immediately.
Cleaning
WARNING
Danger of electric shock
■ Do not bring the device into contact with moisture or water.
■ Always pull out the power supply plug before starting to clean the device.
Device Cleaning
Housing Use a microfiber cloth to remove light and stubborn dirt.
Illuminant Clean off dirt with a dust brush or a dry, soft cloth.
NOTE
Do not clean the illuminant with water. Even slightest residues on the
illuminant can cause bursting of the illuminant.

12. Accessories and options

You find optimal accessories for your device in our webshop: www.foto-walser.de.
21707 walimex pro power source adapter for 2Go series
21699 walimex pro batterie 8700mAh 10,8V for 2Go series
15643 walimex Universal Conical Snoot Set Aurora/Bowens

13. Disposal and environmental protection

Dispose of the device at a legally specified collection point, such as with the manufacturer,
electronics brands or at a local disposal depot. This service is free of charge.

14. Reference to the declaration of conformity

"WALSER GmbH & Co. KG. hereby declares that the remote control and integrated radio
receiver are compliant with the general requirements and all other applicable regulations of the
directive 2014/53/EU". The Declaration of Conformity is available from the following address:
info@walimexpro.de.
Remedy
Plug the mains cable in
correctly.
Charge the battery.
Switch on the device.
Increase the power of the
dimmer control.
Connect our service.
37
