16 Wet/dry LED indicator
In addition to numeric measurement display in % of relative material moisture, the LED display also
provides a material-dependent evaluation of moisture. The LED display bar becomes larger, from left
to right, with increasing moisture content. The 12-position LED display is subdivided into 4 green (dry),
3 yellow (moist) and 5 red (wet) segments. Wet material causes an additional acoustic signal.
Green = dry
! The classification „dry" means that materials in a heated room have reached a balanced moisture
level and are thus suitable for further processing.
Material temperature compensation
17
Relative material moisture is dependent
on the temperature of the material.
The device automatically compensates
different material temperatures in that
it measures ambient temperature and
uses this measurement for its internal
calculation.
However, the measuring device
also offers an option for setting the
temperature manually to increase
measuring accuracy. This value is
not stored and must be set again
each time the device is switched on.
Temperature units of measure setting
18
The units of measure for ambient
temperature and material com-
pensation can be set to either
°C or °F. The setting is stored
and remains in effect until it is
changed manually.
MultiWet-Master
Yellow = moist
1 sec
5 x
1 sec
4 x
Red = wet
–
+
GB 21
