Gearbox (Fig. 7)
Oil level control: Use oil SAE 80. Verify the oil level every 60 hours: put the machine on flat surface, remove the cap (1) and check if the oil reaches
the hole bottom edge. In case you need to fill it on you have to perform it from the same hole. Go on with such operation until you see the oil coming
out. Screw both cap again.
Oil change: change the oil every 150 hours. The oil drain has to be performed when the machine is hot: remove cap (1) and tilt the machine to a
complete emptying, then put the machine on flat land, fill it in with oil through the hole until the oil starts coming out from it. Screw both cap again.
ATTENTION ! Waste fuel oil is a polluting material: don't waste it in the sorroundings, please apply to suitable waste material centres.
NOISE LEVEL AND VIBRATION LEVEL
(A). Handlebars vibrations according to EN 1033 and ISO 5349. Maximum measured value = 3,9 m/s². Acoustic power value according to 2000/14/
CE Lwa = 94 dB (A), with a uncertainty value K = ± 1,87 dB (A).
TECHNICAL DETAILS
width : 570 mm - Forward speed : 3,6 km/h - Reverse speed : 2,0 km/h - Maximum load on a flat surface : 100 kg - Maximum volume : 85 Lt. - As far
as concerns the engine technical specifications, please see the enclosed instructions booklet.
TROUBLESHOOTING
FAULT
The engine does not start
The engine power goes down
In case you are not able to remedy the defect/damage according to a.m. table, please contact an authorized service center only .
ACCESSORIES
8
plastic collector.
Acoustic pression value (working place) according to the Directive 98/37/CE LA e q = 82,2 dB
Maximum lenght : 1435 mm - Maximum width : 705 mm - Maximum high : 910 mm - Mass : 56 kg - External wheels
Before performing any maintenance and clearing work operation , please take the spark-plug cap off.!
Front snow blade with adjustable handle - Snow chains pair for pneumatic wheels - Sheet platform cm. 59x81 equipped with
FAULT CLEARANCE
Check the fuel level, if necessary refuel.
Check the throttle to be on START position.
Check the spark-plug connector to be properly attacched.
Check the spark-plug condition and if necessary replace it.
Check the fuel valve to be in the opened position( only for the models showing such
feature).
The air filter is dirty – please clean it.
Check the tines to be fasten to the shaft.
