don't try to switch the engine on but move the machine away from the area in order to avoid ignition source until the gasoline vapours fade
away. Re-place the tank caps and the gasoline box.
8 Keep attention to the exhaust pipe. The parts near the pipe can reach 80°C. Replace the defective and/or worn out silencers.
Burn hazards !!!
9 Do not use the wheelbarrow on slopes higher than 35°, as it could overturn. If you are working on slopes, go up/go down straightly, avoid
to drive the unit crosswise. Be careful when you change your direction.
10 Do not load the wheelbarrow with higher weights than the ones shown on the label sticked on the internal tank side, neither fill with objects
overhanging the driver sight nor objects extending beyond the tank dimensions: such behaviour could compromise the wheelbarrow stability
and guidability.
11 When you overturn the tank, we recommend you to stay exclusively on the handlebar side. Please, be careful about the kind of loading
with your unit: if the contents are iced or sticky you risk to overturn the wheelbarrow.
12 Before putting the machine into operations, check it visually and make sure all the accident prevention measures are working. It is absolutely
forbidden to exclude and/or to tamper with them.
13 In case the machine is incorrectly used, and/or the repairs are performed by non-authorized technical staff, and/or fitted by non-original spare
parts: any use other than that described above is prohibited and will involve the cancellation of the warranty and the refuse all responsability
from the manufacturer.

SAFETY DEVICE

All the wheelbarrows are equipped with an accident prevention device. Such device causes the clutch release and the machine stopping on the single
or reverse speed position, to the release of the control lever, furthermore such device avoids the reverse speed insertion if the single speed is on.
Wheels insertion device on 3 positions : (Fig.2)
The wheelbarrow is provided with a special device called "FORK 3 POSITIONS"
On position 1 (free) the wheel turns free on the shaft in order to let the machine to move even if the engine is not working;
On position 2 (blocked) the wheel is working with the shaft, working as on motion, i.e. ready to start working, such position is the most common used;
On position 3 (semi-differential unit) the wheel can perform about a half-turn turning on the shaft, in order to allow turns.
WARNING ! All the works on the fork must be performed when the engine is stopping .
WHEELBARROW ASSEMBLY
The wheelbarrow is delivered to destination, partially assembled in its own packaging, unless otherwise agreed.
TO ASSEMBLE THE OVERTURNING PLATE WITH THE TANK
sembled part. 1 in the packaging), lay them on the unit close to the unblock pins (2) and press on them (not at the same time), lock the overturning
plate making the pins (2) to pass through the plate holes (3). Fig. 9 - Insert the S terminal (1) of the overturning tank wire into the slot (2) of the lever
(3). Then insert the adjuster (4) into the nib cut slot (5).
RIGHT HAND HANDLEBAR ASSEMBLY
chassis next to the welded screws (3) using the enclosed washers (4) and nuts (5). Then screw again (1) after inserting the handlebar.
6
LEFT SIDE –HAND HANDLEBAR
screws (1), the washers (3) and the nuts (5): lower the whole in order to make the overturning plate and the left handlebar to couple the unit (part. 2).
(FIG. 4) Unscrew the screws (1) from the unit, fix the right –hand handlebar (2) directly to the
(FIG. 5) Fix the left-hand handlebar (4) to the overturning plate (2) into the holes using the enclosed
(FIG. 3 - 9) Take the plate and the tank (you can find them as-
