EB1 - Expansion Board 1
5

Start-up

NOTES
Siemens AG 477 791 4070 76 J AA-74
SIMOVERT MASTERDRIVES
After installation of the EB1 terminal expansion board has been completed, an
automatic self-test is carried out when the basic unit (converter/inverter) is
powered up.
If you want to use an input or output of the optional board, you have to activate
the respective function block.
Please bear in mind that if two EB1 terminal expansions are installed, each
board is provided with its own parameter set.
Please refer to the Compendium for further information regarding
parameterization of the EB1 terminal expansion board.
Operating Instructions
Start-up
5-1
