Technical Data
Digital inputs
•
Voltage range LOW
•
Voltage range HIGH
•
Input resistance
•
Smoothing
•
Electrical isolation
Bidirectional digital inputs/outputs
As input
•
Voltage range LOW
•
Voltage range HIGH
•
Input resistance
As output
•
Voltage range LOW
•
Voltage range HIGH
2-2
DI1, DI2, DI3
0 V (- 33 V ... + 5 V)
+ 24 V (+ 13 V ... + 33 V)
4 kΩ
250 µs
none
DIO1, DIO2, DIO3, DIO4
0 V (- 33 V ... + 5 V)
+ 24 V (+ 13 V ... + 33 V)
4 kΩ
open
> P24 ext. -2.5 V / 100 mA
