English
Pending on the size of the baby put the belt ends back through the appropriate shoulder
belt slots (H). To elongate (fig. 2a) the harness belts (E), press the metal belt adjuster (I) and
simultaneously pull the harness belts forwards.
To shorten (fig. 2b) the harness belts (E), just pull the belt end element (J).
It is recommended to check the belt position regularly and to adjust it to the size of your
growing baby. The belts must lie firmly against the baby's body and may not be twisted.
After you have made sure the shoulder belts (E) are set to the right level, pull both shoulder
belts over your baby's shoulder. Bring the ends of the shoulder belts together and push them
into the belt buckle. The belt buckle is correctly engaged if you here a clear "click" (fig. 8).
Tighten the shoulder belts again by pulling the belt end element (J).
The belts must lie firmly against the baby's body and may not be twisted
3. Installing the
capsula BB
®
3.1. Preparation (fig. 3)
The seat can be placed on all passenger seats in the car equipped with
three-point seat-belts. It must not be positioned on the centre back seat however, if this is
only equipped with a lap seat-belt! The seat can be placed on the front passenger seat with
some constraints (no active air bag) or on the back seats of the car.
The baby seat is ALWAYS to be installed in REBOARD position!
3.2. Installation on the front passenger seat
0+ on the front passenger seat, first push the seat back as far as
To install the capsula BB
®
possible and put the back rest in the most upright position. The headrest must also be placed
in the lowest position.
c -capsula.com
3
0+
car seat into your car
Warning: The front passenger seat airbag must be deactivated or removed.
Make sure that you are always fully informed about the airbag by asking the respective
car dealer or official garage about it and getting them to do the necessary work for
you. A wrongly installed or a non-deactivated airbag can cause fatal injuries to your
child or dead in the case of accident!
3.3. Installation on front passenger or back seats (fig. 4 )
The tree-point-belt of a vehicle (fig. 6) is made of 4 parts: the lap belt (O),
the diagonal belt (N), the belt latch (P) and the belt buckle (Q).
Put the seat shell (A) on to the car seat with its back to the driving direction
(«REBOARD»).
Slide the lap belt through the side belt guides (B) marked by a blue arrow on the right
and left side of the seat shell (A) and fasten the vehicle's three-point belt with an
audible «click» sound in the belt lock. Tighten the belt again by pulling it towards
the belt retracting system.
Fig. 5
Finally fix the diagonal belt of the vehicle belt in the rear belt guide (C)
marked by a blue flash. Ensure that the carrying handle (G) is in the horizontal position
(security position, fig. 7a).
Warning: Do not use any other method of securing the baby car seat as the
one described here. Respect the blue markings for the belt guides.
The belt buckle of the adult seat-belt must not come in the way of the weight
distribution points (belt locks, etc.). In any case of doubt contact the dealer,
manufacturer HEYNER MOBIL AUTOMOTIVE GMBH and/or the official garage.
c -capsula.com
English
GB
4
