Stand-alone Mode

In the stand-alone mode, the LED IP T1000 QCL can be used without DMX-controller. Disconnect the LED
IP T1000 QCL from the DMX-controller.

Control Board

The Control Board offers several features: you can simply set the starting address or run the pre-
programmed program.
The main menu is accessed by pressing Menu until the display is lit. Browse through the menu by pressing
Up or Down. Press the Enter button in order to select the desired menu. You can change the selection by
pressing Up or Down. Confirm every selection by pressing the Enter button. You can leave every mode by
pressing the Menu button. The functions provided are described in the following sections.
Default settings shaded.
Main
Sub menu
menu
ADDR
001~ XXX
R
G
B
W
SHUT
STAT
PRSC
CAL
CHMD
SET
LIN, SQR, ISQR,
DIM
Display
0-255
0-255
0-255
0-255
0-255
None, R, G, B,
W, RGW, RGB,
Yellow, Pink,
Cyan, Orange,
Violet, Golden,
2700 K, 3200 K,
4000 K, 5500 K,
6500 K, RGBW
R 0-255
G 0-255
B 0-255
W 0-255
USE Yes/No
10CH
7CH
6CH
5CH
4CH
3CH
SCUR, LIN.,
SQR., ISQR.,
SCUR.
DMX address setting
Dimmer intensity of LED colors
(Master mode)
Please note: In order to save the color
value set via the UP/DOWN button,
press ENTER twice (until the display
shows xxx*).
Strobe effect with increasing speed
Preset colors and color temperatures
(Master mode)
Max. output limitation of LED colors/
White balance
Setting DMX channel mode
LIN - Linear dimmer curve, response
characteristics of LED,
SQR - Square dimmer curve,
response characteristics of LED,
ISQR - Inverse square dimmer curve,
response characteristics of LED,
SCUR - S-shaped dimmer curve,
response characteristics of LED,
LIN. - Linear dimmer curve, response
characteristics of halogen lamp,
SQR. Square dimmer curve, response
characteristics of halogen lamp,
ISQR. - Inverse square dimmer curve,
response characteristics of halogen
lamp,
SCUR. - S-shaped dimmer curve,
response characteristics of halogen
lamp
