EuroLite LED IP T1000 QCL Bedienungsanleitung Seite 37

21 25 15 19 8% 10%
26 30 1A 1E 10% 12%
31 35 1F 23 12% 14%
36 40 24 28 14% 16%
41 45 29 2D 16% 18%
46 50 2E 32 18% 20%
51 55 33 37 20% 22%
56 60 38 3C 22% 24%
61 65 3D 41 24% 25%
66 70 42 46 26% 27%
71 75 47 4B 28% 29%
76 80 4C 50 30% 31%
81 85 51 55 32% 33%
86 90 56 5A 34% 35%
91 95 5B 5F 36% 37%
96 100 60 64 38% 39%
101 110 65 6E 40% 43%
111 115 6F 73 44% 45%
116 120 74 78 45% 47%
121 125 79 7D 47% 49%
126 130 7E 82 49% 51%
131 135 83 87 51% 53%
136 140 88 8C 53% 55%
141 145 8D 91 55% 57%
146 150 92 96 57% 59%
151 155 97 9B 59% 61%
156 160 9C A0 61% 63%
161 165 A1 A5 63% 65%
166 170 A6 AA 65% 67%
171 175 AB AF 67% 69%
176 180 B0 B4 69% 71%
181 185 B5 B9 71% 73%
186 190 BA BE 73% 75%
191 195 BF C3 75% 76%
196 200 C4 C8 77% 78%
201 255 C9 FF 79% 100%
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Decimal Hexad. Percentage S/F
0 10 00 0A 0% 4%
11 11 0B 0B 4% 4%
12 50 0C 32 5% 20%
51 51 33 33 20% 20%
52 90 34 5A 20% 35%
91 91 5B 5B 36% 36%
92 130 5C 82 36% 51%
131 131 83 83 51% 51%
S CT03 - Control Board setting color (CTST, custom color set)
S CT04 - Control Board setting color (CTST, custom color set)
S CT05 - Control Board setting color (CTST, custom color set)
S CT06 - Control Board setting color (CTST, custom color set)
S CT07 - Control Board setting color (CTST, custom color set)
S CT08 - Control Board setting color (CTST, custom color set)
S CT09 - Control Board setting color (CTST, custom color set)
S CT10 - Control Board setting color (CTST, custom color set)
S AUTO 1 (R, G, B, W, RG, RB, GB, GB, RGBW)
S AUTO 2 (R>, R<, G>, G<, B>, B<, W>, W<)
S AUTO 3 (R>G>, R<G<, R>B>, R<B<, B>G>, B<G<)
S AUTO 4 (R>G>B>W>, R<G<B<W<)
AUTO 5 (Rainbow effect: B, BG>, BG,B<, G, G, GR>, GR, G<, R, R,
S RB>, RB,R<B)
S CHASER 1
S CHASER 2
S CHASER 3
S No function
S Red
S Green
S Blue
S White
S RGW
S RGB
S Yellow
S Pink
S Cyan
S Orange
S Violet
S Golden
S WHITE color temperature 2700 K
S WHITE color temperature 3200 K
S WHITE color temperature 4000 K
S WHITE color temperature 5500 K
S WHITE color temperature 6500 K
S RGBW
S No function
Control-channel 8 - Speed internal programs (AUTO 1 - 5)
F Decreasing speed
Control-channel 9 - Color-change linear
in combination with control-channel 5
S No function
S Blue
F Red 0% / green increasing / blue 100%
S Cyan
F Red 0% / green 100% / blue decreasing
S Green
F Red increasing / green 100% / blue 0%
S Yellow
37/40
Feature
Feature
00102016, Version 1.0
