EuroLite LED IP T1000 QCL Bedienungsanleitung Seite 36

31 40 1F 28 30% 41%
41 50 29 32 42% 53%
51 60 33 3C 53% 65%
61 70 3D 46 65% 76%
71 80 47 50 77% 88%
81 90 51 5A 89% 100%
91 255 5B FF 89% 100%
10 channel mode
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Decimal Hexad. Percentage S/F
0 5 00 05 0% 2%
6 20 06 14 2% 8%
21 60 15 3C 8% 24%
61 100 3D 64 24% 39%
101 140 65 8C 40% 55%
141 180 8D B4 55% 71%
181 220 B5 DC 71% 86%
221 255 DD FF 87% 100%
Decimal Hexad. Percentage S/F
0 10 00 0A 0% 4%
11 15 0B 0F 4% 6%
16 20 10 14 6% 8%
S Inverse square dimmer curve, response characteristics of LED
S S-shaped dimmer curve, response characteristics of halogen LED
S Linear dimmer curve, response characteristics of halogen lamp
S Square dimmer curve, response characteristics of halogen lamp
Inverse square dimmer curve, response characteristics of halogen
S lamp
S S-shaped dimmer curve, response characteristics of halogen lamp
S Control Board setting dimmer curve
Control-channel 1 - Dimmer
F Gradual adjustment of the dimmer intensity from 0 to 100 %
Control-channel 2 - Red
F Red (0=off, 255=100% red)
Control-channel 3 - Green
F Green (0=off, 255=100% green)
Control-channel 4 - Blue
F Blue (0=off, 255=100% blue)
Control-channel 5 - White
F White (0=off, 255=100% white)
Control-channel 6 - Strobe
S No function
F Strobe-effect (asynchron) with increasing speed
F Strobe-effect (synchron) with increasing speed
F Strobe-effect (sinus wave) with increasing speed
F Random strobe-effect with increasing speed
F Opening pulse-effect with increasing speed
F Closing pulse-effect with increasing speed
F Strobe-effect (square wave) with increasing speed
Control-channel 7 - Color presets, internal programs
S No function
S CT01 - Control Board setting color (CTST, custom color set)
S CT02 - Control Board setting color (CTST, custom color set)
36/40
Feature
Feature
Feature
Feature
Feature
Feature
Feature
00102016, Version 1.0
