OPERATION

After you connected the effect to the mains, the LED IP PAR Z60 RGBW starts running.
The OLED display lights up and you can now choose the desired settings via the buttons MENU, UP, DOWN
and ENTER.
The device has two operating modes. It can be operated in stand-alone mode or in DMX-controlled mode via
any standard DMX controller.

Stand-alone Mode

In the stand-alone mode, the LED IP PAR Z60 RGBW can be used without DMX-controller. Disconnect the
LED IP PAR Z60 RGBW from the DMX-controller.

Control Board

The Control Board offers several features: you can simply set the starting address or run the pre-
programmed program.
The main menu is accessed by pressing Menu until the display is lit. Browse through the menu by pressing
Up or Down. Press the Enter button twice in order to select the desired menu. You can change the selection
by pressing Up or Down. Confirm every selection by pressing the Enter button. You can leave every mode
by pressing the Menu button. The functions provided are described in the following sections.
Default settings shaded.
Main
Sub menu
menu
ADDR 001~ XXX
R
G
B
STATIC
W
ZOOM
SHUT
CAL
CHMD
SET
DIM
Display
0-255
0-255
0-255
0-255
0-255
0-255
R 0-255
G 0-255
B 0-255
W 0-255
USE Yes/No
11CH
7CH
5CH
LIN, SQR,
ISQR, SCUR,
LIN., SQR.,
ISQR., SCUR.
DMX address setting
Dimmer intensity of LED colors
(Master mode)
Please note: In order to save the color
value set via the UP/DOWN button, press
ENTER twice (until the display shows
xxx*).
Zoom from small to big
Strobe effect with increasing speed
Max. output limitation of LED colors/
White balance
Setting DMX channel mode
LIN - Linear dimmer curve, response
characteristics of LED,
SQR - - Square dimmer curve, response
characteristics of LED,
ISQR - Inverse square dimmer curve,
response characteristics of LED,
SCUR - S-shaped dimmer curve,
response characteristics of LED,
LIN. - Linear dimmer curve, response
characteristics of halogen lamp,
SQR. Square dimmer curve, response
27/36
Function
