EuroLite LED IP PAR Z60 RGBW Bedienungsanleitung Seite 31

Decimal Hexad. Percentage
0 5 00 05
6 20 06 14
21 60 15 3C
61 100 3D 64 24% 39%
101 140 65 8C 40% 55%
141 180 8D B4 55% 71%
181 220 B5 DC 71% 86%
221 255 DD FF 87% 100%
11 channel mode
Decimal Hexad. Percentage
0 255 00 FF
Decimal Hexad. Percentage
0 255 00 FF
Decimal Hexad. Percentage
0 255 00 FF
Decimal Hexad. Percentage
0 255 00 FF
Decimal Hexad. Percentage
0 255 00 FF
Decimal Hexad. Percentage
0 255 00 FF
Decimal Hexad. Percentage
0 5 00 05
6 20 06 14
21 60 15 3C
61 100 3D 64 24% 39%
101 140 65 8C 40% 55%
141 180 8D B4 55% 71%
181 220 B5 DC 71% 86%
221 255 DD FF 87% 100%
Control-channel 7 - Strobe
S/F
0% 2% S No function
2% 8% F Strobe-effect (asynchron) with increasing speed
8% 24% F Strobe-effect (synchron) with increasing speed
F Strobe-effect (sinus wave) with increasing speed
F Random strobe-effect with increasing speed
F Opening pulse-effect with increasing speed
F Closing pulse-effect with increasing speed
F Strobe-effect (square wave) with increasing speed
Control-channel 1 - Dimmer
S/F
0% 100% F Gradual adjustment of the dimmer intensity from 0 to 100 %
Control-channel 2 - Red
S/F
0% 100% F Red (0=off, 255=100% red)
Control-channel 3 - Green
S/F
0% 100% F Green (0=off, 255=100% green)
Control-channel 4 - Blue
S/F
0% 100% F Blue (0=off, 255=100% blue)
Control-channel 5 - White
S/F
0% 100% F White (0=off, 255=100% white)
Control-channel 6 - Zoom
S/F
0% 100% F Gradual adjustment from 4° - 32°
Control-channel 7 - Strobe
S/F
0% 2% S No function
2% 8% F Strobe-effect (asynchron) with increasing speed
8% 24% F Strobe-effect (synchron) with increasing speed
F Strobe-effect (sinus wave) with increasing speed
F Random strobe-effect with increasing speed
F Opening pulse-effect with increasing speed
F Closing pulse-effect with increasing speed
F Strobe-effect (square wave) with increasing speed
Feature
Feature
Feature
Feature
Feature
Feature
Feature
Feature
31/36 00106191, Version 1.0
