Description; Features; Overview - EuroLite LED SLS-603 TCL + UVFloor Bedienungsanleitung

DESCRIPTION

Features

Slimline LED spot with 6 x 3W LEDs
Operable in stand-alone mode or via DMX interface
•
DMX512 control possible via any commercial DMX controller (occupies max. 8 channels)
•
4 or 8 DMX channels selectable for numerous applications
•
Master/Slave function for synchronous operation with several devices
•
Sound-control via built-in microphone
•
Microphone-sensitivity adjustable
•
Equipped with 5 x 3 W TCL LEDs in red, green and blue and one 3 W UV LED
•
Flat housing form requires minimal space when rigging
•
Designed for hanging or standing installation
•
Second mounting bracket for safe standing installation
•
Additional rubber feet when the spot should be positioned on the floor without mounting bracket
•
Power supply input and output and DMX input and output oppositely attached to the unit for easier
•
wiring
Comfortable addressing and setting via control panel with LED display and four operating buttons
•
• Additional controlling possibility via the EUROLITE IR-7 remote control, included in delivery
• Functions: Static colors, RGBUV color blend, internal programs, dimmer, strobe, sound-control
Programmable internal program speed and strobe effect
•
Ready for connection via included IEC power cord with safety power plug
•
Feed-through output allows to power up to 8 devices
•
Switch-mode power supply for operation between 100 and 240 Volts
•

Overview

1 2 3
front
1
(1) Fixation screws
(2) IR receiver
(3) TCL LEDs
19/27 00095594, Version 1.0
