Fuses, losses and frame sizes
Type
ACS355
x = E/U
1-phase UN = 200...240 V
01x-02A4-2
01x-04A7-2
01x-06A7-2 16/20
01x-07A5-2 20/25
01x-09A8-2 25/35
3-phase UN = 200...240 V
03x-02A4-2
03x-03A5-2
03x-04A7-2
03x-06A7-2
03x-07A5-2
03x-09A8-2
03x-13A3-2
03x-17A6-2
03x-24A4- 2
03x-31A0-2
03x-46A2-2
3-phase UN = 380...480 V
03x-01A2-4
03x-01A9-4
03x-02A4-4
03x-03A3-4
03x-04A1-4
03x-05A6-4
03x-07A3-4
03x-08A8-4
03x-12A5-4
03x-15A6-4
03x-23A1-4
03x-31A0-4
03x-38A0-4
03x-44A0-4
1)
The rated fuse currents given in the table are the
maximums for the mentioned fuse types for short-
circuit protection of the input power cable. Check that
the operating time of the fuse is below 0.5 seconds. If
the 0.5 seconds operating time is exceeded with the
gG or T fuses, ultra rapid (aR) fuses will in most cases
reduce the operating time to an acceptable level.
Note: Larger fuses must not be used when the input
power cable is selected according to this table.
2)
If 50% overload capacity is needed, use the larger
fuse alternative.
1)
Fuses
gG UL Class T
(600 V)
A A
10 10
16 20
2)
25
2)
30
2)
35
10 10
10 10
10 15
16 15
16 15
16 20
25 30
25 35
63 60
80 80
100 100
10 10
10 10
10 10
10 10
16 15
16 15
16 20
20 25
25 30
35 35
50 50
80 80
100 100
100 100
Heat dissipation
Main circuit Control circuit
Rated /1N and Max
/2N
W W
25 22.7
46 26.4
71 26.4
73 27.5
96 27.5
19 22.7
31 22.7
38 26.4
60 26.4
62 26.4
83 27.5
112 27.5
152 27.5
250 35.4
270 57.8
430 57.8
11 24.4
16 24.4
21 28.7
31 28.7
40 28.7
61 28.7
74 32.7
94 32.7
130 31.2
173 31.2
266 35.4
350 57.8
440 57.8
530 57.8
Air flow Frame
size
m3/h ft3/min
- - R0
24 14 R1
24 14 R1
21 12 R2
21 12 R2
- - R0
- - R0
24 14 R1
24 14 R1
21 12 R1
21 12 R2
52 31 R2
52 31 R2
71 42 R3
96 57 R4
96 57 R4
- - R0
- - R0
13 8 R1
13 8 R1
13 8 R1
19 11 R1
24 14 R1
24 14 R1
52 31 R3
52 31 R3
71 42 R3
96 57 R4
96 57 R4
96 57 R4
