Technical Specifications - HomeMatic HM-Sec-MDIR-3 Bedienungsanleitung

Technical specifications
Hereby, eQ-3 AG, Maiburger Str. 29, 26789 Leer/Germany
declares that the radio equipment type Homematic HM-Sec-
MDIR-3 is in compliance with Directive 2014/53/EU. The full
text of the EU declaration of conformity is available at the fol-
lowing internet address: www.eq-3.com
12

Technical specifications

Device short description:
Supply voltage:
Current consumption:
Battery life:
Degree of protection:
Ambient temperature:
PIR sensor characteristics:
- Main lens
· Range/sensing angle:
- Creep zone protection
· Range/sensing angle:
Swivel range:
Receiver category:
Duty cycle:
Radio frequency band:
Maximum radiated power:
Typ. open area RF range:
Dimensions (ø x H):
Weight:
Subject to technical changes.
58
HM-Sec-MDIR-3
3x 1.5 V LR6/mignon/AA
45 mA max.
2 years (typ.)
IP20
-10 to +55 °C
approx. 12 m/approx. 90°
approx. 4 m/approx. 43°
± 45°
SRD category 2
< 1 % per h
868.0–868.6 MHz
10 dBm
300 m
55 x 132 mm
180 g (including batteries)
