tor again.
• Depending on the teach-in variant used (see sec. "6.4
Teaching-in" on page 46), the brightness criterion (e.g.
only switch when dark) may also be transferred.
7.3

Brightness values

The integrated brightness sensor provides brightness values
over a wide measuring range. These brightness values can
be used as decision criterion in central control unit programs
or direct device connections.
The following diagram shows the assignment of the bright-
ness value to the illumination intensity.
HM-Sec-MDIR
HM-Sec-MDIR-3
250
200
150
100
50
0
0,01 0,1
Homematic Wireless Motion Detector: exemplary brightness values
1
Illumination intensity [lx]
Other notes on operation
10 100 1000 10000 100000
53
