ELECTRIC STAPLER PET 25 C2

Introduction

Congratulations on the purchase of your new appli-
ance. You have chosen a high-quality product. The
operating instructions are part of this product. They
contain important information about safety, usage
and disposal. Before using the product, please
familiarise yourself with all operating and safety
instructions. Use the product only as described and
for the range of applications specified. Please also
pass these operating instructions on to any future
owner.

Intended use

This electric staple gun is intended for stapling
cardboard, insulating material, leather, material
(textiles or natural fibre) and comparable materials
onto softwoods or plywood-like material in private
households. The appliance is only for use in dry
rooms. Any other uses of or modification to the
appliance is deemed to be improper and carries
the risk of serious personal injury. The manufacturer
accepts no responsibility for any damage attribut-
able to misuse. This appliance is not intended for
commercial use.

Description of components

Trigger
ON/OFF switch
Impact force control
Magazine slider
Rip fence
Magazine
Scale
Fill level indicator
Face plate

Package contents

1 electric stapler PET 25 C2
300 staples 25 mm
200 staples 15 mm
300 nails 32 mm
200 nails 25 mm
1 hex key
1 set of operating instructions
│ GB │ IE │ NI │ CY
■ 2

Technical data

Type:
Rated voltage:
Rated current:
Operations:
30 / min
Short-term operation
Dureé /
Duration
(SO):
KB
max.
15 min
Protection class:
Staple width:
Staple length:
Type 55
15–25 mm
Nail length:
Type 47
15, 20, 25,
32 mm
Noise and vibration data:
Noise measurement value determined in accord-
ance with EN 60745. The A-rated noise level of
the power tool is typically as follows:
Sound pressure level:
Sound power level:
Uncertainty:
Wear hearing protection!
Vibration values determined in accordance with
EN 60745:
Vibration emission value: a
Uncertainty K = 1.5 m/s
PET 25 C2
230 V∼ (AC) 50 Hz
3.7 A
up to 30 impacts/
min
max. 15 min
II /
(Double insulation)
6 mm
15–25
15, 20, 25, 32 mm
L = 87.4 dB(A)
pA
L = 98.4 dB(A)
WA
K = 3 dB
pA/WA
= 3.417 m/s 2 ,
h
2 .
PET 25 C2
