5 Electrical installation
Standard devices in the power range 15 ... 30 kW
Mains choke/mains filter assignment
5.5.4 Mains choke/mains filter assignment
9300 Mains choke
Type
EVS9327−xx ELN3−0088H035−001
EVS9328−xx ELN3−0075H045
EVS9329−xx ELN3−0055H055
1)
RFI filter
2)
Footprint filter
176
Interference voltage category according to EN 61800−3 and motor cable length
Component
C2 max. [m]
EZN3A0110H030
E82ZN22334B230
1)
E82ZZ15334B230
EZN3A0080H042
E82ZN22334B230
EZN3A0055H060
E82ZN30334B230
l
Component
C1
25 E82ZN22334B230
E82ZZ15334B230
50 EZN3B0110H030U
50
25 E82ZN22334B230
50 EZN3B0080H042
25 E82ZN30334B230
50 EZN3B0055H060
EDKVS9332X DE/EN/FR 8.0
max. [m]
10
1)
10
2)
50
10
50
10
50
