2. Mounting of the enclosure
The RAYSTAT-CONTROL-10 can be installed indoor or outdoor.
Do not install the thermostat under the thermal insulation.
A. Wall mounting
Mount the enclosure using wall fasteners (screws) via the four,
4 mm ∅ holes.
B. Mounting on a pipe
Tyco Thermal Controls offers different support brackets (not included) to
mount the RAYSTAT-CONTROL-10 on a pipe: SB-100, SB-101 or SB-110.
3. Wiring
Remove the terminal protection cover to access the terminals.
Power cable:
Enter a single phase (230 Vac.) power cable through the M25 gland 2
(see drawing A ) and wire according to the wiring diagram (page 37).
Wiring the heating cable can be done either:
A. Via junction box or contactor or when using RayClic with the cold cable
through the M25 gland 3 .
B. Directly into RAYSTAT-CONTROL-10.
In this case, the M25 gland 3 , which is delivered pre-mounted to the
RAYSTAT-CONTROL-10, is to be replaced by an appropriate kit.
Follow instructions supplied with the kit for installation.
Important: For Voltage Free Operation, the wire links (W1) and (W2) need
to be removed. Failure to remove the wire links can result in damage to the
unit or to other connected equipment. Wiring of RAYSTAT-CONTROL-10 to
a remote alarm is optional through the M20 gland 4 . It is strongly recom-
mended to use a remote alarm for critical operations (e.g. when extreme low
temperatures (lower than –25°C) can be expected or for critical processes).
