To alter any parameter shown in the display, press the + or – keys. This
will allow the parameter to be raised or lowered to the maximum or the mini-
mum in integer steps.
If you require to reset all parameters to their default value, press the + and
– keys together for about 2 sec. If this is succesful, the display will show
.
3. Parameters
The first parameter to show up during Set-up mode is the Set Point. Other
parameters, their default, minimum and maximum values are shown in the
below table:
Parameter
Set Point (°C)
Hysteresis (K)
Low Temperature Alarm
1
Threshold (°C)
High Temperature
Threshold (°C)
Heater Operation if
Sensor Error
Voltage Free Operation
1
Max. Low Temp. Alarm is always smaller than Set Point minus hysteresis.
2
Min. High Temp. Alarm is always larger than Set Point plus hysteresis.
3
Consider also max. exp. temp. of heating cable in table,to select an
appro priate High Temp. Alarm value. If one does not want the High Temp.
Alarm to be active, set the value to
Default Displayed
Value Code
5
1
0
65
1
0
, which comes after 150.
Min. Max.
0 150
1 5
–40 148
2
2 150
0 (OFF) 1 (ON)
0 (NO) 1 (YES)
1
3
