Ersatzteilliste / Spare Parts List
Pos.
Bezeichnung:
A1
Leiterplatte WIG-Steuerung DC-
Teil ACTIG03/2
Drehknopf ∅ 31mm
B1
Deckel für Drehknopf ∅ 31mm
Pfeilscheibe für Drehknopf
∅ 31mm
C1
Leiterplatte WIG-Steuerung
INTIG03/4
Drehknopf ∅ 23mm
D1
Deckel für Drehknopf ∅ 23mm
Pfeilscheibe für Drehknopf
∅ 23mm
E1
Potentiometer
F1
LED-Anzeige (Strom) DVM1/1-1
G1
Kippschalter
H1
Anschlußbuchse 5 polig
I1
Schweißstrombuchse
J1
Gasanschluß ¼"
K1
Anschlußbuchse 14 polig EB3
Entstörplatine LC3/1
L1
Kabelverschraubung
Gegenmutter
M1
Netzkabel
N1
Gehäuseabdeckung
O1
Gummifüsse
P1
Sicherungshalter mit Mutter
Sicherungskappe
Sicherung
0,63A/6,3X32MM/250V/träge
Q1
Seitenblech
R1
Gasventil
S1
Hauptschalter EIN/AUS
Schaltergriff
T1
Halterung für Griffstange
Griffstange
o. Abb. Zentralanschluß
o. Abb. Kunststoffgehäuse für
Zentralanschluß
Description
TIG PCB control for the DC
ACTIG03/2
Knob ∅31mm
Cover for knob ∅ 31mm
Arrow indicator for knob
∅31mm
PCB TIG control INTIG03/4
Knob ∅23mm
Cover for knob ∅ 23mm
Arrow indicator for knob
∅23mm
potentiometer
LED-display (current) DVM1/1-1
Toggle switch
Torch connection 5 pole
Welding current socket outlet
Gas connection ¼"
Connection socket 14-pole EB3
PCB for connection socket
14-pole LC3/1
Cable inlet
Lock nut
Mains cable
Outer housing
Rubber feet
Fuse holder with nut
Fuse cap
Fuse
0,63A/6,3X32MM/250V/out-fuse
Side panel
Gas valve
Mains ON/OFF switch
Switch handle
Holder for hand grip
Hand grip
Central connection
Plastic housing for central
connection
9 / 2
Art. Nr. / art. no.
040-000379-00002
074-000234-00000
074-000234-00001
074-000234-00002
094-001545-00005
074-000315-00000
074-000315-00001
074-000315-00002
044-001513-00000
040-000385-00000
094-001898-00000
074-000233-00000
074-000232-00000
094-000047-00001
040-000408-00000
040-000482-00000
094-003293-00000
024-000205-00001
092-000661-00000
094-003383-00009
094-002876-00000
094-000001-00000
094-000001-00001
094-005477-00000
094-005215-00002
074-000227-00000
074-000279-00000
094-001814-00000
074-000237-00000
074-000237-00013
094-000316-00000
094-001759-00000
