Electrical Characteristics; Safety Devices - EdilKamin TINY Installationsanleitung

THERMOTECHNICAL CHARACTERISTICS
Nominal power
Efficiency nominal power
Emissions CO (13% O2) nominal power
Smoke mass nominal power
Reduced power
Efficiency reduced power
Emissions CO (13% O2) reduced power
Smoke mass reduced power
Maximum overheated smoke
Minimum draught
Autonomy (min/max)
Fuel consumption (min/max)
Hopper capacity
*
Heatable volume
Weight including packaging (Tiny/Kelly)
Smoke outlet pipe diameter (male)
Air intake pipe diameter (male)
*
The heatable room dimensions are calculated on the basis of pellets with an lhv of at least 4300 kcal/kg and home insulation in
compliance with Italian law 10/91, and subsequent changes together with an expected heat output of 33 Kcal/m³ per hour.
* It is also important to consider the position of the stove in the room to be heated.
The data shown above is purely indicative.
EDILKAMIN s.p.a. reserves the right to make changes to these products to improve their performance with
no prior warning.

ELECTRICAL CHARACTERISTICS

Power supply
Average power consumption
Power consumption during ignition
Remote control frequency (optional)
Remote control frequency (as standard)
Protection on electronic circuit board

SAFETY DEVICES

THERMOCOUPLE:
placed at the smoke outlet to detect the temperature.
Turns the stove on and off and controls its operation based on defined parameters.
AIR FLOW SENSOR:
placed in the air inlet channel.
This intervenes if an anomaly is detected in the combustion air flow and causes insufficient circulation in the smoke ducts.
SAFETY THERMOSTAT:
trips when the temperature inside the stove is too high. It stops pellet loading, causing the stove to go out.
FEATURES
34
9
94,1
149
5,8
2,8
96,2
206
2,1
111
12
10/33
0,6/2
20
235
217/189
80
40
230Vac +/- 10% 50 Hz
100 W
400 W
Infrared
Radio waves 2.4 GHz
2AT, 250 Vac, 5x20 Fuse
