Übersicht über das Mainboard D3348
Power
2x
USB 2.0
2x
USB 2.0
LAN/
2x USB 3.0
Audio
FAN 1
25MHz
Crystal
Power
CPU
PCH
CPU
CPU
PCH
PCH
External connectors rear
D3348-A
2
SLOT7 PCIe x4 (Gen3)
SLOT6 PCIe x16 (Gen3)
SLOT5 PCIe x4 (Gen2)
SLOT4 PCIe x4 (Gen3)
SLOT3 PCIe x16 (Gen3)
SLOT2 PCIe x1 (Gen2)
SLOT1 PCIe x1 (Gen2)
Front FAN 4
USB2.0
Audio
LAN
CPU
2x USB 3.0
CPU
Front
Battery
25MHz
Crystal
32 kHz Crystal
9 7 3 1
8 6 2 0
SATAX3 Ports SATA3 Ports
FAN 1 = rear-fan
FAN 2 = CPU-fan
FAN 3 =
F
PC 2009 = PSU-fan
Mainboard D3348
Drive
Power
FAN 2
PCH
FAN 3
USB 2.0
Intern
5
4
T2V AUX
USB 2.0 Front
front fan
AN 4 = Door-fan
