Power Supply Considerations

Power Connectors
The D3348 is operated with a 12 V power supply or an ATX power supply.
12V power connector (D3348-A)
Pin 9 Pin 1
16-pin board power connector
Pin 5 Pin 1
8-pin connector to supply the drives
ATX power supply (D3348-B)
16-pin board power connector
Fujitsu
Pin 7 Pin 1
12-pin board power connector
Pin 4 Pin 1
6-pin board power connector
8-pin board power connector
