Prior to installation

Checking for absence of faults

After unpacking, check the package content for completeness and
the absence of faults. If, although not to be expected, there are rea-
sons for complaint, please contact the appropriate sales person
without delay. Later complaints, unfortunately, cannot be accepted.

Recommended accessories for Hygienic Design

Description
HD wall spacer bracket,
Stainless steel 1.4301 (AISI 304)
Wall separation:
– 50 mm
HD levelling feet,
Stainless steel 1.4301 (AISI 304)
Levelling range: 120 – 175 mm
Variant:
– without base attachment
– with base attachment
HD cable gland,
Stainless steel 1.4305 (AISI 303)
Variant:
– M12 x 1.5
– M16 x 1.5
– M20 x 1.5
– M25 x 1.5
– M16 x 1.5 EMC
– M20 x 1.5 EMC
– M25 x 1.5 EMC
– Lock nut M12 x 1.5
– Lock nut M16 x 1.5
– Lock nut M20 x 1.5
– Lock nut M25 x 1.5
– Installation tool for M12 to M25
Rittal Hygienic Design assembly instructions
Packs of Model No. HD
1 4000.100
2 4000.220
2 4000.230
5 2410.000
5 2410.010
5 2410.020
5 2410.030
5 2410.110
5 2410.120
5 2410.130
10 2410.200
10 2410.210
10 2410.220
10 2410.230
1 set 2410.290
